KSZ9567R_V01 datasheet(112/233 Pages) MICROCHIP

112 / 233 page

KSZ9567R

DS00002329E-page 112

 2022 Microchip Technology Inc. and its subsidiaries

5.1.5.10

ALU / Static Address Table Entry 1 Register

This register contains the table entry values for read and write operations to the Address Lookup Table and Static

Address Table. The field definitions of this register differ dependent on the table type used, as defined in the following

sections:

• ALU Table Entry 1 Register on page 190

• Static Address Table Entry 1 Register on page 192

Refer to Section 5.3.1, "Address Lookup (ALU) Table," on page 187 and Section 5.3.2, "Static Address Table," on

page 191 for additional information.

5.1.5.11

ALU / Static Address / Reserved Multicast Table Entry 2 Register

The field definitions of this register differ dependent on the table type used, as defined in the following sections:

• ALU Table Entry 2 Register on page 190

• Static Address Table Entry 2 Register on page 192

• Reserved Multicast Address Table Entry 2 Register on page 194

Refer to Section 5.3.1, "Address Lookup (ALU) Table," on page 187, Section 5.3.2, "Static Address Table," on page 191,

and Section 5.3.3, "Reserved Multicast Address Table," on page 193 for additional information.

5.1.5.12

ALU / Static Address Table Entry 3 Register

The field definitions of this register differ dependent on the table type used, as defined in the following sections:

• ALU Table Entry 3 Register on page 191

• Static Address Table Entry 3 Register on page 193

Refer to Section 5.3.1, "Address Lookup (ALU) Table," on page 187 and Section 5.3.2, "Static Address Table," on

page 191 for additional information.

5.1.5.13

ALU / Static Address Table Entry 4 Register

This register contains the table entry values for read and write operations to the Address Lookup Table and Static

Address Table. The field definitions of this register differ dependent on the table type used, as defined in the following

sections:

• ALU Table Entry 4 Register on page 191

• Static Address Table Entry 4 Register on page 193

Refer to Section 5.3.1, "Address Lookup (ALU) Table," on page 187 and Section 5.3.2, "Static Address Table," on

page 191 for additional information.

Address:

0x0420 - 0x0423

Size:

32 bits

Address:

0x0424 - 0x0427

Size:

32 bits

Address:

0x0428 - 0x042B

Size:

32 bits

Address:

0x042C - 0x042F

Size:

32 bits
