DESCRIPTION
The TEN06 series offer 6 watts of output power from a 1.61 x 1.02 x 0.33 inch package without derating to 50ºC and without external input/output capacitor. The TEN06 series with 2:1 wide input voltage of 4.5-9, 9-18, 18-36 and 36-75VDC and features 500VAC of isolation, short-circuit protection.

FEATURES
• 6 WATTS MAXIMUM OUTPUT POWER
• OUTPUT CURRENT UP TO 1200mA
• PACKAGE, 1.61 x 1.02 x 0.33 INCH
• HIGH EFFICIENCY UP TO 85%
• 2:1 WIDE INPUT VOLTAGE RANGE
• FIVE-SIDED SHIELD
• SWITCHING FREQUENCY 100K TO 1500KHz.
• NO EXTERNAL INPUT AND OUTPUT CAPACITOR NEEDED
• LOW RIPPLE & NOISE
• OVER CURRENT PROTECTION
• SHORT CIRCUIT PROTECTION
• LONG LIFE WITHOUT ELECTROLYTIC CAPACITOR
• CE MARK MEETS 2006/95/EC, 93/68/EEC AND 2004/108/EC
• DESIGN MEETS J60950-1, UL60950-1, EN60950-1 AND IEC60950-1
• ISO9001 CERTIFIED MANUFACTURING FACILITIES
• COMPLIANT TO RoHS EU DIRECTIVE 2002/95/EC

APPLICATIONS
    Wireless Network
    Telecom/Datacom
    Industry Control System
    Measurement Equipment
    Semiconductor Equipment
