Configuration

• SSMB Jack Connector

• MIL-STD-348

• 50 Ohms

• Right Angle Body Geometry

• Thru Hole Interface Type

• Solder Attachment

Features

• Gold Plated Contact

• Contact plating according to MIL-G-45204

Applications

• General Purpose Test

• Space Saving for PCB Applications

.

Description

Pasternack’s PE4341 SSMB jack right angle connector with solder attachment for thru hole PCB (.100 inch x .031 inch hole

spacing) is part of our full line of RF components available for same-day shipping. Its right angle body geometry allows for

easier connections in tight spaces.

Our SSMB jack right angle connector PE4341 datasheet specifications and drawing with dimensions are shown below in

this PDF. Pasternack’s broad catalog of RF, microwave and millimeter wave connectors allows designers to configure and

customize their signal connections however they like. Whether the need is to provide an I/O for a board design, or simply

create a custom cable assembly configuration, Pasternack has the right connector for the job. Pasternack can also expertly

build your custom cable assemblies for you and ship same-day.

Mechanical Specifications

Size

Length

0.383 in [9.73 mm]

Width/Dia.

0.156 in [3.96 mm]

Height

0.383 in [9.73 mm]

.

Weight

0.004 lbs [1.81 g]

.

Material Specifications

Description

Material

Plating

Contact

Gold

MIL-G-45204

Insulation

PTFE

Body

Brass

Gold

MIL-G-45204

.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: SSMB Jack Right Angle Connector Solder Attachment Thru Hole PCB, .100 inch x .031 inch

Hole Spacing PE4341

PE4341 REV 1.1

SSMB Jack Right Angle Connector Solder Attachment

Thru Hole PCB, .100 inch x .031 inch Hole Spacing

RF Connectors Technical Data Sheet

PE4341
