7 / 25 page

Data Sheet

ADL5513

Rev. A | Page 7 of 25

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage, VPOS

5.5 V

VSET Voltage

0 V to VPOS

Input Power (Single-Ended, Re: 50 Ω)

20 dBm

Internal Power Dissipation

220 mW

θJA

79.3°C/W

Maximum Junction Temperature

150°C

Operating Temperature Range

−40°C to +125°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

260°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

ESD CAUTION
