S486

CMOS IC

UNISONIC TECHNOLOGIES CO., LTD

3 of 12

www.unisonic.com.tw

QW-R502-074.D



С)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply voltage (Note 2)

6

V

Input Voltage

V

Continuous(Note 3)

SOP-8

0.71

W

С)

MSOP-8

0.58

W

Junction Temperature

+150

°

С

Operating Temperature

-40 ~ +85

°

С

Storage Temperature

-65 ~ +150

°

С

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. All voltage values are measured with respect to the ground pin.

for an extended time period is dramatically reducing product life expectancy.



T H ERM AL DAT A

PARAMETER

SYMBOL

RATINGS

UNIT

SOP-8

175

°

С/W

Junction to Ambient

MSOP-8

215

°

С/W



RECOM M EN DED OPERAT I N G CON DI T I ON S

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

2 ~ 5.5

V

ACTIVE

1.5

V

Standby Voltage Input

STANDBY

GND

V

Load Resistor

≥16

Ω

Ω

400

pF

Load Capacitor

Ω

100

pF

Junction to Ambient

150

/W

℃
