WRZ8000 datasheet(1/2 Pages) DH

1 / 2 page

Modules

Operation elements

Weather sensors

Performance features

» Compact ventilation control panel

» For activating 230 V AC ventilation drives

» For controlling up to 20 ventilation groups in conjunction with cut‑off

relay modules

» Input for external controller, e.g. timer

» Central weather monitoring function (central CLOSED) in conjunction

with multiple TRL 8

» LED displays for wind and rain

» Continuous configuration of the wind strength switch point (2 ‑ 8 Bft.)

and signal retention time (1 ‑ 15 minutes)

» Exceeding wind switching threshold and automatic mode ON / OFF

» Bargraph display for wind strength (Beaufort) and LED for wind signal

save function

» Surface‑mounted plastic housing

WRZ Series CNV control panel

WRZ 8000

Accessories

We reserve the right to make changes.
