Technical Data 4120

Effective October 2015

Supersedes March 2007

Product description

•

Surface mount inductors, 4.0mm height,

designed for higher speed switch mode applica-

tions requiring low voltage and high current

•

Design utilizes high temperature powder iron

material with a non-organic binder to eliminate

thermal aging

•

Inductance Range from 0.175 uH to 47.3 uH

•

Current Range from 2.2 to 76 Amps

•

Frequency Range 1kHz to 500kHz

Applications

•

Multi-phase regulators

•

Voltage Regulator Modules (VRMs)

•

Distributed power systems DC-DC converters

•

Desktop and server VRMs and EVRDs

•

Point-of-Load (POL) modules

•

Field Programmable Gate Array (FPGA) DC-DC

converters

•

Battery power systems

•

High current power supplies

•

Data networking and storage systems

Environmental data

•

Storage temperature range (component):

-40°C to +155°C

•

Operating temperature range: -40°C to +155°C

(ambient plus self-temperature rise)

•

Solder reflow temperature:

J-STD-020D compliant

HC8

High current power inductors

Pb
