TECHNICAL DATA SHEET

ATE-R11-7W

3 / 8

A/1

ATE-R11-7W/D/C-B II

SERIES

Revision issued in 2013.

3-2. ELECTRICAL-OPTICAL CHARACTERISTICS

**

PARAMETER

SYMBOL

CONDITION

MIN.

TYP.

MAX.

UNIT

common

34.8

36

39.6

V

Beam Angle

—

—

120

—

Deg

W

**

Color Temp.

—

2870

3045

3220

K

**

Ra

80

—

—

—

Φ

578

612

—

lm

Luminous Efficiency

η

85

90

—

lm/W

Φ

626

653

—

lm

Luminous Efficiency

η

92

96

—

lm/W

D

**

Color Temp.

—

4745

5028

5311

K

**

Ra

80

—

—

—

Φ

653

687

—

lm

Luminous Efficiency

η

96

101

—

lm/W

Φ

700

734

—

lm

Luminous Efficiency

η

103

108

—

lm/W

C

**

Color Temp.

—

6020

6530

7040

K

**

Ra

80

—

—

—

Φ

714

734

—

lm

Luminous Efficiency

η

105

108

—

lm/W

Φ

748

780

—

lm

Luminous Efficiency

η

110

115

—

lm/W

(Note) Parameters is formulated based on shipping samples

*1. After 20 ms drive, Measurement tolerance: ± 3 %

*2. Monitored by TOPLITE's 1m integrating sphere, after 20 ms drive, Measurement tolerance: ± 10 %

*3. Monitored by TOPLITE's 1m integrating sphere, after 20 ms drive, Measurement tolerance:± 2
