REVISION HISTORY

Table 19. Document Revision History

Date

Rev.

Description of Revision

Jan-1999

1.0

Document written

13-Feb-2002

2.0

Document reformatted using the new template

Voltage range -S added, and -R removed

Instruction Sequence illustrations updated

Announcement made of planned upgrade to 10 MHz clock for the 5V, –40 to 85°C, range

05-Dec-2003

3.0

added, and -S removed

02-Apr-2004

4.0

Old versions of document completely replaced by one rewritten from M95256

03-Jan-2005

5.0

AC and DC characteristics tables updated with the performance data of the new device

identified with the process letter “A”.

Table 1., Product List added. AEC-Q100-002 compliance. Device Grade information clarified.

M95512 part number with 4.5V to 5.5V operating voltage range removed (related tables

removed). Document status changed to Preliminary Data.

30-Jun-2005

6.0

Updated Figure 4., Bus Master and Memory Devices on the SPI Bus and Figure 17., Hold

Timing. Power On Reset information clarified. Protected Array Addresses modified in Table

4., Write-Protected Block Size. Ambient Operating Temperature value added in Table

12., DC Characteristics (M95512-W, Device Grade 6). All values modified in Table 15., AC

Characteristics (M95512-R). Document status changed to Datasheet.
