1 / 4 page

Product description

• Unshielded, leaded drum core

• Protective sleeveing over winding

• Inductance range from 10μH to

33,000μH

• Current range from 0.042A to 2.9A

• 7.9 OD x 9.0mm through-hole package

• Ferrite core material

• Halogen free, lead free, RoHS compliant

Applications

• LED Drivers and lighting

• Utility meters

• Appliance electronics

• Motor drives

• Power supplies

• General purpose filtering

Environmental data

• Storage temperature range (Component):

-40°C to +125°C

• Operating temperature range: -40°C to +125°C

(ambient + self-temperature rise)

Coiltronics RL0809 Series

Unshielded radial leaded drum core inductors

Technical Data 10279

Effective June 2014

Coiltronics is now

part of Eaton

Same great

products plus

even more.

The Coiltronics brand of

magnetics (formerly of

the Bussmann Division of

Cooper Industries)

is now part of

Eaton’s Electrical Group,

Electronics Division.

HALOGEN

HF

FREE

Pb
