Product data sheet

Characteristics

NET3T

Network SurgeArrest 3 Outlet w/Tel 120V

NET3T has not been replaced. Please contact your customer

care center for more information.

Overview

Model Name

Network SurgeArrest 3 Outlet w/Tel 120V

Includes

1.8 Meter Tel cable (2) , User Manual

Standard Lead Time

Usually in Stock

Product Distribution

Canada , Mexico , United States

Output

Number of Outlets

3

Receptacle Style

NEMA 5-15R

Input

Nominal Input Voltage

120V

Input Frequency

50/60 Hz +/- 5 Hz (auto sensing)

Input Connections

NEMA 5-15P

Maximum Line Current per phase

15.0 A

Surge Protection and Filtering

Surge energy rating

480 Joules

EP Joule Rating

3420 Joules

EMI/RFI Noise rejection (100 kHz to

10 MHz)

70.0 dB

Peak Current Normal Mode

13 kA

Peak Current Common Mode

26.0 kA

Data Line Protection

RJ-11 Modem/Fax/DSL protection (two wire single line)

Data Lines Protected(multi-line only)

--

Let Through Voltage Rating

40

Physical

Net Weight

1.0 lbs (0.45 kg)

Maximum Height

2.0 inches (51.0 mm)

Maximum Width

4.25 inches (108.0 mm)

Apr 8, 2020

1
