General Purpose Transistors

MAXIMUM RATINGS

Rating

Symbol

Value

Unit

Collector–Emitter Voltage

V CEO

50

V

Collector–Base Voltage

VCBO

60

V

Emitter–Base Voltage

VEBO

7.0

V

Collector Current — Continuous

I C

150

mAdc

Collector power dissipation

PC

0.2

W

Junction temperature

Tj

150

C

Storage temperature

Tstg

-55 ~+150

C

h FE values are classified as follows:

Q

R

S

hFE

120~270

180~390

270~560

2

EMITTER

3

COLLECTOR

1

BASE

*

NPN Silicon

FEATURE

Low Cob,Cob=2pF(Typ.).

Epitaxial planar type.

PNP complement : FTA1576

DEVICE MARKING AND ORDERING INFORMATION

Device

Marking

Shipping

FTC4081-Q

BQ

3000/Tape&Reel

FTC4081-Q

BQ

10000/Tape&Reel

FTC4081-R

BR

3000/Tape&Reel

FTC4081-R

BR

10000/Tape&Reel

FTC4081-S

BS

3000/Tape&Reel

FTC4081-S

BS

10000/Tape&Reel

2008. 4. 20

1/5

SEMICONDUCTOR

TECHNICAL DATA

FTC4081

Revision No : 0

1

3

2

SC-70 / SOT– 323
