Features

SMB

●

For surface mounted applications

●

Low reverse leakage current

RoHS

●

Low forward voltage drop

COMPLIANT

●

High surge capacity

●

Meet UL flammability classification 94V-0

Mechanical Data

●

Case: JEDEC SMB molded plastic

●

Polarity: Color band denotes cathode

●

Mounting position: Any

Note: Products with logo

are made byHY Electronic (Cayman) Limited.

Applications

●

For use in low voltage, high frequency inverters,

polarity protection applications

Maximum Ratings and Electrical Characteristics

Rating at 25℃ ambient temperature unless otherwise specified.

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

Characteristics

Symbol

S3AB

S3BB

S3DB

S3GB

S3JB

S3KB

S3MB

Unit

Maximum Repetitive Peak Reverse Voltage

VRRM

50

100

200

400

600

800

1000

V

Maximum RMS Voltage

VRMS

35

70

140

280

420

560

700

V

Maximum DC Blocking Voltage

VDC

50

100

200

400

600

800

1000

V

Maximum Average Forward Rectified Current @TL=75 ℃

I(AV)

A

Peak Forward Surge Current, 8.3mS Single Half Sine-Wave,

Superimposed on Rated Load (JEDEC Method)

I

2t Rating for Fusing (t<8.3mS)

I

2t

A

2s

Peak Forward Voltage at 3.0A DC (Note1)

VF

V

Maximum DC Reverse Current @TJ=25℃

at Rated DC Blocking Voltage @TJ=125℃

Typical Junction Capacitance (Note 2)

CJ

pF

Typical Thermal Resistance Junction to Lead

RθJL

℃/W

Typical Thermal Resistance Junction to Ambient

RθJA

℃/W

Operating Junction Temperature Range

TJ

℃

Storage Temperature Range

TSTG

℃

Notes: 1. 300uS pulse width, 2%duty cycle.

2. Measured at 1.0 MHz and applied reverse voltage of 4.0V DC.

3. The typical data above is for reference only .

S3*B-13-00/99-00/01

Rev. 11, 18-May-2020

www.hygroup.com.tw

S3AB THRU S3MB

uA

IFSM

100

A

5.0

Pb

Surface Mount Glass Passivated Rectifiers

Package Outline Dimensions in Inches (Millimeters)

Reverse Voltage - 50 to 1000Volts

1.1

41.5

-55 to+150

Forward Current - 3.0 Amperes

IR

250

10

40

3.0

-55 to+150

50

or
