SST-90-R Product Datasheet

All SST-90 products are packaged and labeled with their respective bin as outlined in the tables on page 4. When shipped, each package

will only contain one flux and chromaticity bin.

The part number designation is as follows:

SST

90

X

F11

FF

WW

Product Family

Chip Area

Color

Package Configuration

Flux Bin

Wavelength Bin

Surface Mount

(Lens)

R: Red

F11: Surface mount, shipped

in 25 unit trays.

R11: Surface mount Starboard

PCB, shipped in trays.

See page 3 for bins

See page 3 for bins

Example:

The part number SST-90-R-F11-BJ-R3 refers to a red, SST-90 surface mount, with a flux range of 475-600 lumens and a wavelength range of 615 nm to

619 nm.

Note 3: Some flux and chromaticity/ wavelength bins may have limited availability. Application specific bin kits, consisting of multiple bins, may be

available. For ordering information, please refer to pages 4 and 5.
