Specifications

Graphics core

“Vega” GPU with up to 11 Compute Units

DisplayPort

4x outputs with resolution up to 4096 x 2160 @ 60Hz

Interface: PCI Express x1 Bus

Wake On LAN: Yes

Standard Input: ATX = 12V ±5%/5Vsb ±5% from internal header

AT = 12V ±5% from internal header

Peripherals output: Onboard headers for fan and SATA power

Form Factor: Mini-ITX

Dimensions: 170 mm x 170 mm (L x W)

Operating Temperature

Standard: 0˚C to +60˚C

Certifications

CE, FCC Class A

Relative Humidity

40° C @ 95% RH Non-condensing, Non-operating

Ordering Information

●

AmITX-RZ-G/V1202B

Mini-ITX gaming MB with AMD Ryzen™ Embedded V1202B

processor

●

AmITX-RZ-G/V1605B

Mini-ITX gaming MB with AMD Ryzen™ Embedded V1605B

processor

●

AmITX-RZ-G/V1756B

Mini-ITX gaming MB with AMD Ryzen™ Embedded V1756B

processor

●

AmITX-RZ-G/V1807B

Mini-ITX gaming MB with AMD Ryzen™ Embedded V1807B

processor

Packing List

●

30-20872-0000

ATX/AT Power Cable

●

30-20875-0000

SATA Dual Power Cable

●

30-10057-0600

SATA Cable

●

34-25316-1010

Rear I/O Shield

Optional Accessories

●

30-20876-0000

COM Port Cable, 1 Port, 25cm

●

30-20874-1000

USB 2.0 Cable, 2 ports, 20cm

●

32-20809-0000-A0

AMD APU Cooler, H=64.4mm, 54W

●

32-20583-1010

AMD APU Cooler, H=35mm, 35W
