Features & Benefits

•

Developed according to ISO 26262, compliant with the requirements of ASIL B(D)

•

Low jitter 0.02% due to high switching accuracy enables iTPMS

•

Two-wire current interface providing speed and direction information

•

Advanced stop-start capabilities enabled by

-

Innovative watchdog concept to guarantee maximum signal availability

-

No loss of direction information during start-stop condition

•

Wide operating junction temperature range -40°C to 190°C

•

Robustness against external magnetic disturbances up to 2mT through differential sensing principle

•

High sensitivity enables outstanding air gap performance along with immunity against y-displacement

effects

•

Small sensor package 5x3mm without need of external capacitor saves module size, increases robustness

against mechanical stress, and enables design freedom

•

Advanced EMC concept maximizes the availability of the sensor signal

•

New established Micro Break feature designed to be immune against disturbances on supply line

Order Information

Table 1

Type

Description

Ordering

Number

TLE5046iC-PWM2-R050

Speed sensor with direction detection and PWM protocol,

SP002627824

TLE5046iC-PWM2-R100

Speed sensor with direction detection and PWM protocol,

SP002627830

TLE5046iC-PWM2E-R050

Speed sensor with direction detection, additional self-

diagnostics, and PWM protocol, optimized for use with load

SP002627816

TLE5046iC-PWM2E-R100

Speed sensor with direction detection, additional self-

diagnostics, and PWM protocol, optimized for use with load

SP002627820

TLE5046iC-AK-LR

Speed sensor with direction detection and AK protocol

SP001418756

TLE5046iC-AK-ERR

Speed sensor with direction detection, additional self-

diagnostics, and AK protocol

SP001615796

TLE5046iC

Technical product description

About this product

Technical Product Description

2

Revision 2.0

2020-06-30
