Data Sheet

ADL5206

Rev. 0 | Page 5 of 25

Test Conditions/Comments

Min Typ

Max

Min

Typ

Max Unit

DIGITAL INTERFACE

Input Voltage

MODE1, MODE0, PWUP,

LATCH, and SDIO pins

2

VPOS

2

3.3

V

0

1.0

0

1.0

V

Input Leakage Current

±3

±3

µA

Output Voltage

SDIO pin

2.4

2.4

2.4

0.5

0.5

POWER INTERFACE

VPOS pin

3.15 3.3

3.45

4.75

5

5.25

V

Quiescent Current

87

112

mA

Power-Down Current

PWUP pin = low

8

8

mA

1

The 3.3 V supply is low power mode, and the 5 V supply is high performance mode.

2

When referring to a single function of a multifunction pin in the specifications table, only the portion of the pin name that is relevant to the specification is listed. For

full pin names of multifunction pins, refer to the Pin Configuration and Function Descriptions section.

3

The maximum input swing of 6.2 V p-p is for the lowest gain setting of 2 dB. As the gain setting increases, the maximum input swing must be reduced correspondingly

to maintain the same maximum output swing. The maximum output swing is based on P1dB.
