MODEL: 40DT

40DT SPECIFICATIONS

ES-9535 Rev.10 Page 4/6

https://www.m-system.co.jp/

PARAMETER LIST

■ ZERO & SPAN ADJUSTMENTS

PARAMETER

DISPLAY

FUNCTION

DEFAULT VALUE

Input type

K thermocouple (usable range -150 to +1370°C, -238 to +2498°F)

J thermocouple (usable range -180 to +1000°C, -292 to +1832°F)

T thermocouple (usable range -170 to +400°C, -274 to +752°F)

R thermocouple (usable range 380 to 1760°C, 716 to 3200°F)

Zero adjustment

–

Adjustment value for 0% of measurement range

To distinguish from span adjustment, the rst decimal point is blink-

ing

Span adjustment

–

Adjustment value for 100% of measurement range

Temperature unit

Display in Celsius

Display in Fahrenheit

■ DISPLAY SETTING MODE

PARAMETER

DISPLAY

FUNCTION

DEFAULT VALUE

Moving Average

No moving averaging

Moving average with 2 samples

Moving average with 4 samples

Moving average with 8 samples

Moving average with 16 samples

Brightness

Brightness level 1 (dark)

Brightness level 2

Brightness level 3

Brightness level 4

Brightness level 5 (bright)

CJC Sensor

CJC sensor Enabled

CJC sensor Disabled

Initialization

Non-initialization

Initialize settings (change to factory settings) *

1

Version Indication

−

Version number, indication only

−

*1. While “

” is shown, pressing Disp/

button or Scale/

button initializes settings.

Activating “initialization”, user’s speci ed parameters will be deleted and overwritten with the factory default values. Notice that after this,

Ex-factory settings will be irrecoverable.
