OUTLINE DIMENSIONS

2.35

2.25

2.15

TOP VIEW

END VIEW

BOTTOM VIEW

1

3

4

6

7

9

10

12

0.53 REF

PIN 1

INDICATOR

0.26

0.22

0.18

0.75

0.70

0.65

0.85

0.75

0.65

0.85

0.80

0.75

0.10 × 0.45°

PIN 1

INDICATOR

0.40

BSC

0.633

BSC

0.567

BSC

0.818

BSC

0.775

BSC

0.125

BSC

0.80 REF

0.250

0.200

0.150

0.325

0.275

0.225

FOR PROPER CONNECTION OF

THE EXPOSED PAD, REFER TO

THE PIN CONFIGURATION AND

FUNCTION DESCRIPTIONS

SECTION OF THIS DATA SHEET.

Figure 26. 12-Terminal Land Grid Array [LGA]

2.25 mm × 2.25 mm Body and 0.75 mm Package Height

(CC-12-3)

Dimensions shown in millimeters

ORDERING GUIDE

Temperature Range

Package Description

Package Option

Marking Code

ADRF5025BCCZN

−40°C to +105°C

12-Terminal Land Grid Array [LGA]

CC-12-3

25

ADRF5025BCCZN-R7

−40°C to +105°C

12-Terminal Land Grid Array [LGA]

CC-12-3

25

ADRF5025-EVALZ

Evaluation Board

1

Z = RoHS Compliant Part.
