 25 / 33 page
background image
Figure 17. ESD Diode Diagram
AGND
SHDN
DCIN
DOUT
VAA
GNDL
CTG
TXP, TXN
VDDL
RXP, RXN
CS, SCLK,
DIN, INT
ALL DIODES ARE RATED FOR ESD CLAMPING CONDITIONS. THEY ARE NOT INTENDED
TO ACCURATELY CLAMP DC VOLTAGE. ALL DIODES SHOWN HAVE A PARASITIC
PN DIODE FROM THEIR CATHODE TO AGND THAT IS OMITTED FOR CLARITY.
THIS PARASITIC DIODE HAS ITS ANODE AT AGND.
MAX17841B ESD DIODES
Internal ESD Protection
Maxim Integrated │ 25
MAX17841B
Automotive SPI Communication Interface (ASCI)
www.maximintegrated.com
