ADRF6755
Data Sheet
Rev. B | Page 38 of 48
CCOMPx Pins
The CCOMPx pins are internal compensation nodes that must
be decoupled to ground with a 100 nF capacitor.
MUXOUT
MUXOUT is a test output that allows different internal nodes
to be monitored. It is a CMOS output stage that requires no
termination.
Lock Detect (LDET)
Lock detect is a CMOS output that indicates the state of the
PLL. A high level indicates a locked condition, and a low level
indicates a loss of lock condition.
TXDIS
This input disables the RF output. It can be driven from an external
stimulus or simply connected high or low by Jumper J18.
RF Output (RFOUT)
RFOUT (J12) is the RF output of the ADRF6755.
