POE-D10-00-E-13

SAFETY STANDARDS REGULATED, REINFORCED

INSULATION TYPE, AH SERIES

Ver: 13

Page: 3 / 18

Record of change (continue)

Date

Version

Description

page

2014/11/5

13

1. Review the size of SL*AH820J*** from 080 to be 090.

2. Review the terminal position of the lead wire.

3. Review the product of ID, add the code “D” for the products of

Dongguan Walsin Technology Electronics Co., Ltd.

4. Review the Operating Temperature Range, from “-25 to +125°C” to be

“-40 to +125°C”.

5. Review the minimum packing quantity of taping code AM.

6. Review the low temperature range from -25°C to -40°C for temperature

cycle test.

6

7

8

11

15

13

Table of Contents

No.

Item

Page

1

Part number for SAP system

4

2

Mechanical

5

3

Part numbering/T.C/Capacitance/ Tolerance/Diameter

6

4

Taping Format

7

5

Marking

8

6

Scope

9

7

Specification and test method

10~13

8

Packing specification

14

9

Notices

15~17

10

Drawing of Internal Structure and material list

18
