MODEL: R6S-PF1

R6S-PF1 SPECIFICATIONS

ES-7781-BF Rev.2 Page 3/3

https://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm [inch]

5.9 (.23)

*Use a minus screwdriver: tip width 3.8 mm max., tip thickness 0.5 to 0.6 mm

102 (4.02)

WIRE INSERTION ANGLE

: approx.35°

TEST PROBE

max. 2 (.08) dia.

SCREWDRIVER

*

INSERTION ANGLE

: approx. 35°

5

6

7

8

1

2

3

4

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

Note: In order to improve EMC performance, bond the FG terminal to ground.

Caution: FG terminal is NOT a protective conductor terminal.

1

4

2

3

POWER LED

RUN LED

NC

NO

COM

5

6

7

8

FG

INTERNAL POWER

INTERNAL BUS

Ry

+

–

POWER INPUT

RUN CONTACT OUTPUT

Specifications are subject to change without notice.
