ENI11HD-R

5

Germany: +49 621 776 1111

Pepperl+Fuchs Group

Refer to "General Notes Relating to Pepperl+Fuchs Product Information".

USA: +1 330 486 0001

Singapore: +65 6779 9091

www.pepperl-fuchs.com

fa-info@us.pepperl-fuchs.com

fa-info@sg.pepperl-fuchs.com

fa-info@de.pepperl-fuchs.com

Heavy-duty incremental encoder

Signal outputs

Connection

Signal

Cable

Connector 9416,

M23, 12-pin

Connector 9416L,

M23, 12-pin

Terminals

GND

White

10

10

0V

Brown

12

12

A

Green

5

5

A

BGrey

8

8

B

A\

Yellow

6

6

A\

B\

Pink

1

1

B\

ZBlue

3

3

Z

Z\

Red

4

4

Z\

Shielding

Shield

Housing

Housing

NC

-

2, 7, 9, 11

2, 7, 9, 11

Operation

i

Type Code

12 11

98 10 7

3

12 6

4

5

87 11

91 12 2

6

10 3

5

4

A0V

A

ZZ

BB



cw - with view from the drive side

A

A

B

B

Z

Z

90° ± 10 %

25 % ± 10 %

50 % ± 10 %
