3.4

Supported video timings

●

4096 x 2160 (4K x 2K) 60 Hz: 24 bits/pixel (DP to DP only)

●

4096 x 2160 (4K x 2K) 24 Hz/30 Hz: 24 bits/pixel (DP to HDMI)

●

1920 x 1080 (FHD) 120 Hz: 24 bits/pixel

●

2560 x 1600 (WQXGA) 60 Hz: 24 bits/pixel

●

Up to 1920 x 1080 (FHD) 60 Hz, 48, 36, 30 bits/pixel

●

All compatible 3D formats defined in DP 1.2 and HDMI 1.4 specifications

●

All standard CEA861 timing formats

3.5

Supported audio timings

●

All audio formats as specified in DP 1.2 and HDMI 1.4 specifications

●

SPDIF; 2-Ch LPCM, AC3, DTS, bit depth up to 24 bits, sample rate up to 192 kHz

3.6

Control channel interfaces

●

AUX CH, I2C host interface, SPI (optional), and UART (UART for test/debug purposes

only)

3.7

HDCP 1.3 support

●

Key sets for DP RX and DP/HDMI TX integrated in one-time programmable ROM

(OTP)

●

Standalone HDCP repeater capability

3.8

Package

●

81 BGA (8 x 8 mm), 0.8 ball pitch

3.9

Power supply voltages

●

3.3 V I/O; 1.2 V core

3.10

ESD

●

2 KV HBM, 500 V CDM
