65 / 226 page  2017-2018 Microchip Technology Inc. DS00002419D-page 65 KSZ9563R 5.1 Global Registers This section details the device’s global registers. For an overview of the device’s entire register map, refer to Section 5.0, "Device Registers". For details on the device’s port registers, refer to Section 5.2, "Port Registers". 5.1.1 GLOBAL OPERATION CONTROL REGISTERS (0x0000 - 0x00FF) 5.1.1.1 Global Chip ID 0 Register 5.1.1.2 Global Chip ID 1 Register 5.1.1.3 Global Chip ID 2 Register 5.1.1.4 Global Chip ID 3 Register Address: 0x0000 Size: 8 bits Bits Description Type Default 7:0 Fixed Value RO 0x00 Address: 0x0001 Size: 8 bits Bits Description Type Default 7:0 Chip ID (MSB) RO 0x98 Address: 0x0002 Size: 8 bits Bits Description Type Default 7:0 Chip ID (LSB) RO 0x93 Address: 0x0003 Size: 8 bits Bits Description Type Default 7:4 Revision ID RO - 3:1 RESERVED RO - 0 Global Software Reset Refer to the Switch Operation Register for another reset control bit. 0 = Normal operation 1 = Resets the data path and state machines, but not register values. R/W SC 0b |
|
