TSSP40..SS1XB

www.vishay.com

Vishay Semiconductors

Datasheet Values Refer to PCN-OPT-1224-2022

Rev. 2.0, 19-Aug-2022

4

Document Number: 82737

THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT

ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000

Fig. 5 - Frequency Dependence of Responsivity

Fig. 6 - Sensitivity vs. Ambient Temperature

Fig. 7 - Relative Spectral Sensitivity vs. Wavelength

Fig. 8 - Horizontal Directivity

Fig. 9 - Sensitivity vs. Supply Voltage

The typical application of this device is a reflective or beam

break sensor with active low “detect” or “no detect”

information contained in its output. The TSSP40.. is also

suitable for fast (~ 15 ms) proximity sensor applications for

ranges between 10 cm and 2 m, if a burst pattern with

variable intensity is used.

Example for a sensor hardware:

There should be no common window in front of the emitter

and detector in order to avoid crosstalk via guided light

through the window.

0.0

0.2

0.4

0.6

0.8

1.0

1.2

0.7

0.9

1.1

1.3

f/f0 - Relative Frequency

16925

f = f

0 ± 5 %

Δf(3 dB) = f

0/10

10

100

1000

10000

4

5

6

7

8

9

10

-30

-10

10

30

50

70

90

Axis Title

T

amb - Ambient Temperature (°C)

10

100

1000

10000

0

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

1.0

750

850

950

1050

1150

Axis Title

λ - Wavelength (nm)

23180

0.6

80°

0°

0.7

0.4

0.2

0

30°

70°

60°

50°

40°

10°

20°

1.0

0.9

0.8

d

rel - Relative Transmission Distance

10

100

1000

10000

6

7

8

9

10

123456

Axis Title

V

S - Supply Voltage (V)

Emitter

TSAL6200

IR detector

Separation to avoid crosstalk

by stray light inside the housing
