ADL5306

ABSOLUTE MAXIMUM RATINGS

Table 2. ADL5306 Absolute Maximum Ratings

Parameter

Rating

12 V

Input Current

20 mA

Internal Power Dissipation

500 mW

135°C/W

Maximum Junction Temperature

125°C

Operating Temperature Range

–40°C to +85°C

Storage Temperature Range

–65°C to +150°C

Lead Temperature Range (Soldering 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Rev. 0 | Page 4 of 16
