P9221-R Datasheet
© 2017 Integrated Device Technology, Inc.
27
October 10, 2017
Table 15. Battery Charge Status
Address and Bit
Register or Bit Field Name
R/W
Default
Function and Description
003AHEX [7:0]
Batt_Charg_status
R/W
00HEX
Battery charge status value sent to transmitter.[a]
[a] Firmware only forwards the data from the application processor to transmitter.
Table 16. End Power Transfer
The application processor initiates the End Power Transfer (EPT).
Address and Bit
Register or Bit Field Name
R/W
Default
Function and Description
003BHEX [7:0]
EPT_Code
R/W
00HEX
EPT_Code sent to transmitter.
Table 17. Read Register – Output Voltage
VOUT =
ADC_VOUT ∗ 6 ∗ 2.1
4095
Address and Bit
Register or Bit Field Name
R/W
Default
Function and Description
003CHEX [7:0]
ADC_VOUT [7:0]
R
00HEX
8 LSB of VOUT ADC value.
003DHEX [7:4]
Reserved
R
0HEX
Reserved.
003DHEX [3:0]
ADC_VOUT [11:8]
R
0HEX
4 MSB of VOUT ADC value.
Table 18. Read Register – VRECT Voltage
VRECT =
ADC_VRECT ∗ 10 ∗ 2.1
4095
Address and Bit
Register or Bit Field Name
R/W
Default
Function and Description
0040HEX [7:0]
ADC_VRECT [7:0]
R
–
8 LSB of VRECT ADC value.
0041HEX [7:4]
Reserved
R
0HEX
Reserved
0041HEX [3:0]
ADC_VRECT [11:8]
R
–
4 MSB of VRECT ADC value.
Table 19. Read Register – IOUT Current
IOUT =
RX_IOUT ∗ 2 ∗ 2.1
4095
Address and Bit
Register or Bit Field Name
R/W
Default
Function and Description
0044HEX [7:0]
RX_IOUT [7:0]
RHEX
–
8 LSB of IOUT. Output current in mA.
0045HEX [7:0]
RX_IOUT [15:8]
RHEX
–
8 MSB of IOUT. Output current in mA
