ADM1175

Rev. 0 | Page 6 of 24

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

VCC Pin

20 V

SENSE Pin

20 V

TIMER Pin

−0.3 V to +6 V

ON/ONB Pin

−0.3 V to +20 V

CONV Pin

−0.3 V to +6 V

GATE Pin

30 V

SDA Pin, SCL Pin

−0.3 V to +7 V

ADR Pin

−0.3 V to +6 V

Storage Temperature Range

−65°C to +125°C

Operating Temperature Range

−40°C to +85°C

Lead Temperature (Soldering

, 10 sec)

300°C

Junction Temperature

150°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Table 3. Thermal Resistance

Package Type

θJA

Unit

10-Lead MSOP

137.5

°C/W

ESD CAUTION
