RB520S30
DIODE
UNISONICTECHNOLOGIESCO.,LTD
2 of 3
www.unisonic.com.tw
QW-R601-011,A
ABSOLUTE MAXIMUM RATINGS (Single Diode @T
A=25℃)
PARAMETER
SYMBOL
RATINGS
UNIT
Maximum Reverse Voltage (DC)
VR
30
V
Average Rectified Forward Current
IOUT
200
mA
Non-repetitive Peak Forward Surge Current
IFSM
1
A
Junction Temperature
TJ
+125
℃
Storage Temperature
TSTG
-40 ~ +125
℃
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
ELECTRICAL CHARACTERISTICS (T
A=25℃, unless otherwise specified)
PARAMETER
SYMBOL CONDITIONS
MIN
TYP
MAX
UNIT
Forward Voltage Drop
V F
IF=200mA
0.6
V
Reverse Leakage Current
IR
VR=10V
1
µA
