MITSUMI

Adjustable Type Coils

K Type Series

Coils, Filters

(1) Inductance

(2) Operational frequency

(3) Variable range of F & L

(4) Internal capacitance

(5) Unloaded Q

Specifications

(1) 1~300µH

(4) -

(2) 0.1~20MHz (5) 40~70

(3) F:±2%

L:±4%

Features

SMD

1000pcs./Reel

K5-S

K5-S2

Specifications

(1) 1~300µH

(2) 0.1~20MHz

(3) F:±2%

L:±4%

(4) -

(5) 40~70

Features

SMD

1000pcs./Reel

K5-N1

Specifications

(1) 1~1200µH

(2) 0.1~20MHz

(3) F:±2%

L:±5%

(4) 5~15000pF 2

(5) 50~80

Features

SMD

1000pcs./Reel

K5-N

Specifications

(1) 1~5900µH

(2) 0.1~20MHz

(3) F:±2%

L:±5%

(4) 5~15000pF 2

(5) 50~100

Features

SMD

1000pcs./Reel
