Click here for the 3D model.

Dimensions



D

25mm +/-0.8mm

D2

15mm +/-0.8mm

T

12mm +/-0.8mm

Packaging Specifications



Packaging

Tray, Box

Packaging Quantity

378

Typical Component Weight

18.6 g

General Information



Series

ESD-R

Style

Round - Toroidal

Cable Type

Round Cable

Description

EMI Core Solid, For Round Cables, Toroidal Cores,

Bare Type

RoHS

Yes

Qualifications

UL94 V-2

Materials

Mn-Zn

Specifications



Temperature Range

-25/+85°C

Effective Frequency

10 MHz (AM Band Range)

ESD-R-25SH

Aliases (UECESDR25SH0000)

KEMET, ESD-R, EMI Cores, Noise Suppression
