Motor cable

NEBM-S1W9-E-2.5-Q5-LE6

Part number: 1450737

General operating condition

Data sheet

Feature

Value

Cable designation

Without label holder

Electrical connection 1, function

Field device end

Electrical connection 1, design

Rectangular

Electrical connection 1, connection type

Socket

Electrical connection 1, cable outlet

Angled

Electrical connection 1, connection technology

Sub-D

Electrical connection 1, number of pins/wires

9

Electrical connection 1, occupied pins/wires

6

Electrical connection for input 1, connection pattern

00995638

Electrical connection 2, function

Control side

Electrical connection 2, connection type

Cable

Electrical connection 2, connection technology

Open end

Electrical connection 2, number of pins/wires

6

Electrical connection 2, occupied pins/wires

6

DC operating voltage range

0 V ... 72 V

Nominal operating voltage DC

24 V

Shield

yes

Cable length

2.5 m

Cable characteristic

Suitable for energy chains

Bending radius, flexible cable installation

≥62 mm

Cable diameter

6.2 mm

Cable design

6 x 0.34 mm²

Nominal conductor cross section

0.34 mm²

Wire ends

Cable end sleeve

Degree of protection

IP65

Note on degree of protection

In mounted state

Ambient temperature

-40 °C ... 80 °C

Ambient temperature with flexible cable installation

-5 °C ... 80 °C

CE marking (see declaration of conformity)

As per EU RoHS directive

UKCA marking (see declaration of conformity)

To UK RoHS instructions

LABS (PWIS) conformity

VDMA24364-B2-L

Note on materials

RoHS-compliant

Material of cable sheath

TPE-U(PUR)

Color cable sheath

Gray

5/19/24 - Subject to change - Festo SE & Co. KG

1/1
