How to Order

MF - R 015/600 - A 05 - 2

Product

Designator

Series

R = Radial Leaded

Component

Hold Current, Ihold

015-016 (0.15 - 0.16 Amps)

Max. Interrupt Voltage, V

Resistance Range

Narrow resistance ranges are available

on all models as defined in Electrical

Characteristics.

Resistance Bins

Narrow resistance ranges can be separated

into packages where each device is within

0.5 ohms of each other.

Packaging Options

- 0 = Bulk Packaging

- 2 = Tape and Reel*

*Packaged per EIA486-B

Maximum Time to Trip at 23 ˚C

1000

100

10

1

0.10

0.00

Fault Current (Amps)

0.50

1.00

1.50

2.00

2.50

3.00

MF-R016/600

MF-R015/600

MF-R/600, REV. E, 11/04

A

B

C

D

E

Physical Characteristics

Model

Max.

Max.

Max.

Min.

Nom.

Style

Lead Dia.

Material

MF-R015/600

13.5

12.6

6.0

4.7

5.0

1

0.65

Sn/Cu

(0.531)

(0.496)

(0.236)

(0.185)

(0.197)

(0.026)

MF-R016/600

16.0

12.6

6.0

4.7

5.0

1

0.65

Sn/Cu

(0.629)

(0.496)

(0.236)

(0.185)

(0.197)

(0.026)

Product Dimensions

Packaging options: BULK: 500 pcs. per bag.

TAPE & REEL: 600 pcs. per reel.

Longer lead lengths available upon request.

MM

(INCHES)

DIMENSIONS =

E

D

B

C

A

Typical Part Marking

Represents total content. Layout may vary.

R015

24001K

MANUFACTURER'S

TRADEMARK

PART

IDENTIFICATION

DATE CODE

(FIRST DIGIT =

LAST DIGIT OF YEAR;

SECOND DIGIT =

MONTH;

NEXT THREE DIGITS =

LOT CODE)

MFG. LOCATION

(K = KOREA

S = CHINA)

Model

Rmin.

Rmax.

R1Max.

Bin

MF-R015/600

6.0

12.0

22.0

N/A

MF-R015/600-A

7.0

10.0

20.0

0.5

MF-R015/600-B

9.0

12.0

22.0

0.5

MF-R015/600-F

7.0

12.0

22.0

0.5

MF-R016/600

4.0

10.0

18.0

N/A

MF-R016/600-A

4.0

7.0

16.0

0.5

MF-R016/600-1

4.0

8.0

17.0

0.5

Resistance Options

Additional Features

■

Ability to withstand AC power cross conditions
