Data Sheet

OP1177/OP2177/OP4177

Rev. I | Page 5 of 24

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

36 V

Input Voltage

VS− to VS+

Differential Input Voltage

±Supply Voltage

Storage Temperature Range

R, RM, and RU Packages

−65°C to +150°C

Operating Temperature Range

OP1177/OP2177/OP4177

−40°C to +125°C

Junction Temperature Range

R, RM, and RU Packages

−65°C to +150°C

Lead Temperature, Soldering (10 sec)

300°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the

operational section of this specification is not implied.

Operation beyond the maximum operating conditions for

extended periods may affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 4. Thermal Resistance

Package Type1

θJA

θJC

Unit

8-Lead MSOP (RM-8)

190

°C/W

8-Lead SOIC_N (R-8)

158

°C/W

14-Lead SOIC_N (R-14)

120

°C/W

14-Lead TSSOP (RU-14)

240

°C/W

1 MSOP is available in tape and reel only.

ESD CAUTION
