Absolute maximum ratings and operating conditions

TS488-TS489

4/32

2

Absolute maximum ratings and operating conditions

Table 2.

Absolute maximum ratings

Symbol

Parameter

Value

Unit

1.

All voltage values are measured with respect to the ground pin.

6V

Input voltage

V

Storage temperature

-65 to +150

°C

Maximum junction temperature

150

°C

Thermal resistance junction to ambient

MiniSO-8

DFN8

215

70

°C/W

MiniSO-8

DFN8

2.

0.58

1.79

W

ESD

Human body model (pin to pin)

2

kV

ESD

Machine model

220pF - 240pF (pin to pin)

200

V

Latch-up

Latch-up immunity (all pins)

200

mA

Lead temperature (soldering, 10sec)

250

°C

3.

heating and destructive dissipation. Exposing the IC to a short-circuit for an extended period of time will

dramatically reduce the product’s life expectancy.

Table 3.

Operating conditions

Symbol

Parameter

Value

Unit

Supply voltage

2.2 to 5.5

V

Load resistor

≥ 16

Ω

Operating free air temperature range

-40 to + 85

°C

Load capacitor:

400

100

pF

Standby voltage input:

TS488 active, TS489 in standby

TS488 in standby, TS489 active

1.5

GND

1.

temperature range.

V

Thermal resistance junction to ambient

MiniSO-8

2.

When mounted on a 4-layer PCB.

190

40

°C/W
