RPM7157-R series

Photo Link Module

Rev.A

1/7

IR Receiver Module

RPM7157-R series

RPM7157-R series are remote control receiver modules. Small-sized, light-weight, and low current consumption

modules have been achieved by using resin mold.

Center frequency

56.9kHz

Applications

All household electric appliances such as TV, DVD, air conditioner and audio equipment.

Features

1) Low current consumption. (1.0mA Typ.)

2) High ripple rejection.

3) 5 types of holders available for each set.

RPM7157-R series

with holders

∗Under development

Straight type

RSIP-A3

L forming

RSIP-A3 V4

SIDE VIEW

RSIP-A3 (H13)

Height to lens

5.5mm

4.8mm

15.0mm

TOP VIEW

RSIP-A3 (H4)

15.9mm

SIDE VIEW

RSIP-A3 (H5)

9.6mm

Products No.

RPM7157-R

∗RPM7157-V4R

∗RPM7157-H13R

∗RPM7157-H4R

TOP VIEW

RSIP-A3 (H8)

7.2mm

RPM7157-H8R

TOP VIEW

RSIP-A3 (H9)

12.0mm

∗RPM7157-H9R

∗RPM7157-H5R

Absolute maximum ratings (Ta = 25

°C)

Parameter

Symbol

Limits

Unit

Supply Voltage

−0.3 to +7.0

−10 to +75

−30 to +100

V

Operating temperature

Storage temperature

Topr

Tstg

mA

2.0

Output Current

lo

˚C

˚C

Recommended operating conditions (Ta = 25

°C)

Parameter

Symbol

Min.

Typ.

Max.

Unit

Supply Voltage

5.0

V

4.5

5.5
