background image
RPM7240-R series
Photo Link Module
Rev.B
1/6
IR Receiver Module
RPM7240-R series
RPM7240-R series are remote control receiver module. Small-sized, light-weight, and low voltage operated (from 2.7V)
modules have been achieved by using resin mold.
Center frequency
40.0kHz
Applications
All household electric appliances such as TV, DVD, air conditioner and audio equipment.
Features
1) Low voltage operation. (VCC=2.7 to 3.6V)
2) Low current consumption. (ICC=0.3mA, VCC=3V)
3) Superior anti VCC noise characteristics.
4) 5 types of holders available to each set.
RPM7240-R series
SIDE VIEW
TOP VIEW
RSIP-A3 (H9)
12.0mm
RPM7240-H9R
RSIP-A3 (H8)
7.2mm
RPM7240-H8R
RSIP-A3 (H13)
15.0mm
RPM7240-H13R
RSIP-A3 (H5)
9.6mm
RPM7240-H5R
RSIP-A3 (H4)
15.9mm
RPM7240-H4R
Height to lens
Products No.
Absolute maximum ratings (Ta = 25
°C)
Parameter
Symbol
Limits
Unit
VCC
6.3
−30 to +100
2.0
V
Output current
Tstg
IO
°C
mA
Supply Voltage
Storage temperature
−10 to +75
Topr
°C
Operating temperature voltage
Recommended operating conditions (Ta = 25
°C)
Parameter
Symbol
Min.
Typ.
Max.
Unit
Supply voltage
VCC
3.0
V
2.7
3.6
