Zero RecoveryRectifier

CSD10060B

www.iscsemi.com

1

FEATURES

· Zero Reverse Recovery

· Zero Forward Recovery

· Extremely Fast Switching

· Positive Temperature Coefficient on VF

APPLICATIONS

· Motor Control

· Power Factor Correction

· Switch Mode Power Supplies

ABSOLUTE MAXIMUM RATINGS(Ta=25℃)

SYMBOL

PARAMETER

VALUE

UNIT

VR

DC Blocking Voltage

600

V

IF(AV)

Average Rectified Forward Current

10

A

IFRM

Repetitive Peak Forward Surge Current

TC=25℃, tP=8.3ms, Half Sine Wave

50

A

IFSM

Non-Repetitive Peak Forward Surge Current

TC=25°C, tP=10ms, Pulse

250

A

PD

Power Dissipation

136

W

TJ

Junction Temperature

-55~175

℃

Tstg

Storage Temperature Range

--55~175

℃

THERMAL CHARACTERISTICS

SYMBOL

PARAMETER

MAX

UNIT

Rth j-c

Thermal Resistance,Junction to Case

1.1

℃

/W
