11

“LF” Lead-Free Construction

Inductance Data (R001)

Temperature Derating

ORDERING PROCEDURE

Prefix

CSS

-

1

- R001 -

J

-

7

Style

“1”= 2 terminal & “1K” = 4 terminal

Resistance Code

Standard 4-digit resistance code

Example: R001 = .001 - R002=.002 - R0005=.0005

Resistance Tolerance Code

J = ±5%, F=±1%

Packaging

Available in 7” (1500pcs)

*For packaging information, see Appendix

WIREWOUND AND FILM TECHNOLOGIES DIVISION

736 Greenway Road • Boone, North Carolina 28607-1860 • Tel: 828-264-8861 • Fax: 828-264-8866 • www.irctt.com

TEST PERFORMANCE

LF

OBSOLETE
