Safety isolating transformer

VB 2,3/2/9

Advantages

Minimum size at high output

Inherently short-circuit proof

Also with dual output voltage for series or parallel connection

Designed for high ambient temperatures

Permanent corrosion protection, high insulation value and maximum

electrical reliability thanks to XtraDenseFill resin encapsulation

Self-extinguishing potting material

Applications

As a mains transformer for adjustment of the voltage and simple electrical

isolation.

As a safety isolating transformer for the safe electrical isolation of the input

and output sides. The transformer is suitable for creating SELV and PELV

circuits because of the limit on the output voltage.

Sample application

Standards

Z

Safety isolating transformer

to: VDE 0570 Part 2-6, DIN EN 61558-2-6, EN 61558-2-6, IEC 61558-2-6,

UL 5085-1/-2, CSA 22.2 No.66

Approvals

W w 1 Z

VDE, UL 5085-1/-2, CSA 22.2 No.66

Picture shows VB 2,0/2/6
