部品番号	JN1AS10ML1-R

部品情報	Small circular connector, 10 pos., Panel mount receptacle

PDF	4 Pages

Scroll/Zoom	100%

メーカー	JAE [Japan Aviation Electronics Industry, Ltd.]

ホームページ	http://www.jae.com

Logo

2 / 4 page

Contact Size X No. of Contacts

#22*10

Applicable Wire (Cross-

sectional Area of Conductor)

Applicable Wire Insulation

Diameter

Polarizing Key Position

Normal position

Material of Contact

Finish of Contact in Connecting

Area

Gold plating

Outer Shell Color

Black

Total Current Rating (A)

Contact Resistance (milliohm)

Dielectric Withstanding

Voltage (1 minute)

AC 900 Vr.m.s.

Insulation Resistance

1,000MΩMIN

Mating Cycles

500 times

Operating Temperature Range

-20 Deg. C to +125 Deg. C

Applicable Contacts

Applicable Housing

Applicable Accessory

Applicable Product Part

Numbers

Applicable Wire Diameter

RoHS compliant

10 substances (2011/65/EU, (EU)2015/863)

REACH compliant

Combination

JN1FS10SL1

JN1FS10SL2

JN1FS10SLK

JN2DS10SL1-R

JN2DS10SL2-R

JN2DS10SL3-R

JN2DS10SLK-R
