HEADER SHAPE

FOOT PRINT

MOUNTING PAD LAYOUT

RECOMMENDED

SHIPPING TUBE

DIMENSIONS (mm)

TYP

A

B

C

Length tube

18

12

0,8

532

Quantity per tube

50

Dimensions in millimeters

Dimensions in millimeters

Information furnished is believed to be accurate and reliable. However, SGS-THOMSON Micr oelectronics assumes no responsibility for the

consequences of use of such information nor for any infringement of patents or other rights of third parties which may result from its use. No

license is granted by implication or otherwise under any patent or patent rights of SGS-THOMSON Microelectronics. Specifications mentioned

in this publication are subject to change without notice. This publication supersedes and replaces all information previously supplied.

SGS-THOMSON Microelectronics products are not authorized for use as critical components in lif esupport devices or systems without express

written approval of SGS-THOMSON Microelectronics.

© 1998 SGS-THOMSON Microelectronics - Printed in Italy - All rights reserved.

SGS-THOMSON Microelectronics GROUP OF COMPANIES

Australia - Brazil - Canada - China - France - Germany - Italy - Japan - Korea - Malaysia - Malta - Morocco

The Netherlands - Singapore - Spain - Sweden - Switzerland - Taiwan - Thailand - United Kingdom - U.S.A.

B

C

A

ORDER CODE

CLP

200

M - TR

Current Limiting Protection

Minimum operation voltage

Package : PowerSO-10

TR = tape and reel

= tube

®
