S3JB datasheet(1/2 Pages) HY

部品番号	S3JB

部品情報	SURFACE MOUNT GLASS PASSIVATED RECTIFIERS

PDF	2 Pages

Scroll/Zoom	100%

メーカー	HY [HY ELECTRONIC CORP.]

ホームページ	http://www.hygroup.com.tw

Logo

1 / 2 page

FEATURES

● Glass passivated chip

● For surface mounted applications

● Low reverse leakage current

● Low forward voltage drop

● High current capability

● Plastic material has UL flammability

classification 94V-0

MECHANICAL DATA

●Case： Molded Plastic

●Polarity:Color band denotes cathode

●Weight: 0.003 ounces,0.093 grams

●Mounting position: Any

Dimensions in inches and (millimeters)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Rating at 25℃ ambient temperature unless otherwise specified.

Single phase, half wave ,60Hz, resistive or inductive load.

For capacitive load, derate current by 20%

CHARACTERISTICS

SYMBOL

S3AB

S3BB

S3DB

S3GB

S3JB

S3KB

S3MB

UNIT

Maximum Recurrent Peak Reverse Voltage

VRRM

50

100

200

400

600

800

1000

V

Maximum RMS Voltage

VRMS

35

70

140

280

420

560

700

V

Maximum DC Blocking Voltage

VDC

50

100

200

400

600

800

1000

V

Maximum Average Forward

Rectified Current

@TL=75 ℃

Peak Forward Surge Current

8.3ms Single Half Sine-Wave

Super Imposed On Rated Load (JEDEC Method)

Maximum Forward Voltage at 3.0A DC

VF

V

Maximum DC Reverse Current

@TJ=25℃

at Rated DC Blocking Voltage

@TJ=100℃

Typical Junction Capacitance (Note1)

CJ

pF

Typical Thermal Resistance (Note2)

RθJL

℃/W

Typical Thermal Resistance (Note3)

RθJA

℃/W

Operating Temperature Range

TJ

℃

Storage Temperature Range

TSTG

℃

~ 33 ~

IR

250

5.0

40

10

-55 to +150

3.Thermal resistance junction to ambient.

-55 to +150

NOTES:1.Measured at 1.0 MHz and applied reverse voltage of 4.0V DC.

2.Thermal resistance junction to lead.

uA

1.2

REVERSE VOLTAGE

- 50 to 1000Volts

POWER DISSIPATION

- 3.0 Amperes

50

S3AB thru S3MB

IFSM

A

I(AV)

3.0

A

200

SURFACE MOUNT

GLASS PASSIVATED RECTIFIERS

SMB

.030(0.76)

.060(1.52)

.096(2.44)

.084(2.13)

.200(5.08)

.220(5.59)

.008(.203)

.002(.051)

.006(.152)

.012(.305)

.160(4.06)

.185(4.70)

.130(3.30)

.155(3.94)

.083(2.11)

.075(1.91)
