Standard Surface Mount Rectifier Diode

GPAS1007

www.iscsemi.com

1

FEATURES

· High Current Capability

· High Efficiency, Low VF

· Low Power Loss

APPLICATIONS

· Switching Mode Converters and Inverters

· General Purpose

· DC to DC Converters

ABSOLUTE MAXIMUM RATINGS(Ta=25℃)

SYMBOL

PARAMETER

VALUE

UNIT

VRRM

VRWM

VR

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

1000

V

IF(AV)

Average Rectified Forward Current

10

A

IFSM

Non-repetitive Peak Surge Current

(8.3ms single half sine wave)

150

A

TJ

Max. Junction Temperature

150

℃

Tstg

Storage Temperature Range

-55~150

℃

THERMAL CHARACTERISTICS

SYMBOL

PARAMETER

MAX

UNIT

Rth j-c

Thermal Resistance,Junction to Case

4.0

℃

/W

2

3

1
