AD8571ARM-R2 datasheet(5/24 Pages) AD

5 / 24 page

AD8571/AD8572/AD8574

Rev. C | Page 5 of 24

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Supply Voltage

6 V

Input Voltage

GND to VS + 0.3 V

Differential Input Voltage

±5.0 V

ESD (Human Body Model)

2000 V

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

THERMAL CHARACTERISTICS

Operating Temperature Range

−40°C to +125°C

θ is specified for the worst-case conditions, that is, θ

specified for a device soldered in a circuit board for SOIC and

TSSOP packages.

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

1 Differential input voltage is limited to ±5.0 V or the supply voltage,

whichever is less.

Table 4. Thermal Resistance

Package Type

Unit

8-Lead MSOP (RM)

190

°C/W

8-Lead TSSOP (RU)

240

°C/W

8-Lead SOIC (R)

158

°C/W

14-Lead TSSOP (RU)

180

°C/W

14-Lead SOIC (R)

120

°C/W
