CONNECTION DIAGRAM AND ORDERING NUMBERS (top view)

TO-220

D

THERMAL DATA

Symbol

Parameter

D

TO-220

Unit

Thermal Resistance Junction-case

Max

Thermal Resistance Junction-ambient

Max

3

62.5

3

50

ABSOLUTE MAXIMUM RATINGS

Symbol

Parameter

Value

Unit

-35

-40

V

V

Output Current

I nternally limited

Power Dissipation

I nternally limited

Operating Junction Temperature Range

0 to 125

Storage Temperature Range

- 65 to 150

Type

TO-220

D

Output Voltage

L7905AC

L7952AC

L7906AC

L7908AC

L7912AC

L7915AC

L7918AC

L7920AC

L7922AC

L7924AC

L7905ACV

L7952ACV

L7906ACV

L7908ACV

L7912ACV

L7915ACV

L7918ACV

L7920ACV

L7922ACV

L7924ACV

L7905ACD2T

L7952ACD2T

L7906ACD2T

L7908ACD2T

L7912ACD2T

L7915ACD2T

L7918ACD2T

L7920ACD2T

L7922ACD2T

L7924ACD2T

-5V

-5.2V

-6V

-8V

-12V

-15V

-18V

-20V

-22V

-24V

(*) AVAILABLE IN TAPE AND REEL WITH ”-TR” SUFFIX

APPLICATION CIRCUIT

L7900AC

2/11
