M95M01-R

Part numbering

37/40

Part numbering

For a list of available options (speed, package, etc.) or for further information on any aspect

of this device, please contact your nearest ST sales office.

The category of second-level interconnect is marked on the package and on the inner box

label, in compliance with JEDEC Standard JESD97. The maximum ratings related to

soldering conditions are also marked on the inner box label.

Table 16.

Ordering information scheme

Example:

M95M01

–

R MN

Device type

M95 = SPI serial access EEPROM

Device function

M01 = 1024 Kbits (131 072 × 8)

Operating voltage

R = VCC = 1.8 V to 5.5 V

Package

MN = SO8N (150 mils width)

MW = SO8W (208 mils width)

Device grade

6 = Industrial temperature range, –40 to 85 °C.

Device tested with standard test flow

Option

blank = standard packing

T = tape and reel packing

Plating technology

P or G = ECOPACK® (RoHS compliant)
