background image
ABSOLUTE MAXIMUM RATINGS
Symbol
Parameter
Value
Unit
VCC
Supply Voltage Range
-0.5 to +7
V
VCC -VEE
Supply Voltage Range
-0.5 to 13
V
VIN
DC Input Voltage
-0.5 to VCC + 0.5
V
VI/O
DC Switch I/O Voltage
VEE - 0.5 to VCC + 0.5
V
IIK
Input Diode Current
± 20
mA
IOK
I/O Diode Current
± 20
mA
IOUT
DC Output Current
± 25
mA
ICC or IGND
DC VCC or Ground Current
± 50
mA
PD
Power Dissipation
500 (*)
mW
Tstg
Storage Temperature
-65 to +150
oC
TL
Lead Temperature (10 sec)
300
oC
Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these condition is not implied.
(*) 500 mW:
≅ 65 oC derate to 300 mW by 10mW/oC: 65 oCto 85 oC
RECOMMENDED OPERATING CONDITIONS
Symbol
Parameter
Value
Unit
VCC
Supply Voltage
2 to 6
V
VEE
Supply Voltage
-6 to 0
V
VCC -VEE
Supply Voltage
2 to 12
V
VIN
Input Voltage
0 to VCC
V
VI/O
DC Switch I/O Voltage
VEE to VCC
V
Top
Operating Temperature:
M54HC Series
M74HC Series
-55 to +125
-40 to +85
oC
oC
tr,tf
Input Rise and Fall Time
VCC = 2 V
0 to 1000
ns
VCC = 4.5 V
0 to 500
VCC = 6 V
0 to 400
M54/M74HC4351/4352/4353
4/16
